The L-6C desktop low-speed centrifuge is small in size and saves limited space in the laboratory. It is suitable for qualitative analysis of serum and plasma in hospitals, biological and chemical laboratories and scientific research, as well as centrifugal detection of food safety.
1. All-steel structure multi-layer explosion-proof design, 304 stainless steel centrifugal chamber, safe and ultra-stable running performance.
2. Using microcomputer processor for precise control, digital display of parameters such as speed and time, key programming, setting parameters such as running speed, RCF, time value, etc.
3. Adopt high-torque brushless frequency conversion motor, easy to operate; maintenance-free, no dust, fast lifting speed.
4. Equipped with a variety of rotors, and various adapters can be designed according to the test requirements, and one machine can be used for multiple purposes.
5. 10 lift rates for selection, quick start and stop.
6. Three-stage vibration reduction, centrifugal effect to achieve the best.
Max Speed | 6000rpm |
Max Volume | 6×50ml |
Timer | 1s~99min |
Dimension | 485×320×255mm |
Speed control accuracy | ±20r/min |
Max RCF | 3660×g |
Noise | ≤ 55 |
Net Weight | 20KG |
Power supply | AC 220V 50HZ 2A |
Optional Rotors:
Rotor No. | Rotor Type | Max speed (r/min) | Capacity | Max RCF (*g) |
NO31601 | Angle rotor | 4000 | 12×10ml | 2150 |
NO31602 | 4000 | 12×15ml | 2150 | |
NO31603 | 4000 | 12×20ml | 2220 | |
NO31604 | 4000 | 18×10ml | 2250 | |
NO31605 | 4000 | 30×7/5ml | 2250 | |
NO31606 | 4000 | 6×50ml | 2100 | |
NO31607 | 4000 | 24×10ml | 2200 | |
NO30638 | Angle rotor | 6000 | 6×15ml | 3660 |
5000 | 6×50ml | 2850 | ||
5000 | 6×100ml | 3130 | ||
NO30607 | 5000 | 12×15ml | 3080 | |
swing rotor | 5000 | 6×10ml | 3460 | |
NO32665 | swing rotor | 4000 | 6×10ml vacuum tube | 2210 |
